XGSCOMB OLT
XGS Combo OLT
It supports dual-mode application, adopting a GPON/XGS-PON dual-mode Combo solution at its core. It can simultaneously support two generations of PON technologies on the same OLT port and ODN fiber.
The device supports a commercial operating temperature range (0～70℃), and industrial-grade wide temperature (-40～85℃). It meets the link budget requirements of GPON Class B+/C+/C++/D and XGS-PON, ensuring stable transmission up to 20km in standard scenarios,40km/60km long-distance.
It supports dual-mode application, adopting a GPON/XGS-PON dual-mode Combo solution at its core. It can simultaneously support two generations of PON technologies on the same OLT port and ODN fiber.
The device supports a commercial operating temperature range (0～70℃), and industrial-grade wide temperature (-40～85℃). It meets the link budget requirements of GPON Class B+/C+/C++/D and XGS-PON, ensuring stable transmission up to 20km in standard scenarios,40km/60km long-distance.
FEATURES
● Single-fiber bi-directional transmission
● Data links TX 9.953Gbps/2.488Gbps, Burst Mode RX 9.953Gbps&2.488Gbps/1.244Gbps
● SFP-DD package
● SC/UPC receptacle optical connector
● Hot-pluggable
● 3.3 V power supply
● Operating case temperature: -5°C to 70°C，-5~85°C，-40~85°C
● High power 1490nm DFB & 1577nm EML and high sensitivity 1310&1270nm APD
● Support 20/40/60km transmission distance with SMF
● SD indication
● Low EMI and excellent ESD protection
● Digital diagnostic monitor interface
● RoHS10 compliant
Applications
● XGS-PON and GPON OLT Class D/C++/C+/B+
● FTTX
|
Part Number
|
OPL Class
|
Temp.
|
Distance
|
|
P2DSC-4155A2
|
CLASS D
|
-5~70℃
|
20Km |
|
P2DSE-4155A2
|
-5~85℃
|
||
|
P2DSI-4155A2
|
-40~85℃
|
||
|
P4DSC-4155A2
|
-5~70℃ | 40Km | |
|
P4DSE-4155A2
|
-5~85℃ | ||
|
P4DSI-4155A2
|
-40~85℃ | ||
|
P6DSC-4155A2
|
-5~70℃ | 60Km | |
|
P6DSE-4155A2
|
-5~85℃ | ||
|
P6DSI-4155A2
|
-40~85℃ | ||
|
P2DSC-4155B2
|
CLASS C++
|
-5~70℃ | 20Km |
|
P2DSE-4155B2
|
-5~85℃ | ||
|
P2DSI-4155B2
|
-40~85℃ | ||
|
P4DSC-4155B2
|
-5~70℃ | 40Km | |
|
P4DSE-4155B2
|
-5~85℃ | ||
|
P4DSI-4155B2
|
-40~85℃ | ||
|
P6DSC-4155B2
|
-5~70℃ | 60Km | |
|
P6DSE-4155B2
|
-5~85℃ | ||
|
P6DSI-4155B2
|
-40~85℃ | ||
|
P2DSC-4155C2
|
CLASS C+
|
-5~70℃ | 20Km |
|
P2DSE-4155C2
|
-5~85℃ | ||
|
P2DSI-4155C2
|
-40~85℃ | ||
|
P4DSC-4155C2
|
-5~70℃ | 40Km | |
|
P4DSE-4155C2
|
-5~85℃ | ||
|
P4DSI-4155C2
|
-40~85℃ | ||
|
P6DSC-4155C2
|
-5~70℃ | 60Km | |
|
P6DSE-4155C2
|
-5~85℃ | ||
|
P6DSI-4155C2
|
-40~85℃ | ||
|
P2DSC-4155D2
|
CLASS B+
|
-5~70℃ | 20Km |
|
P2DSE-4155D2
|
-5~85℃ | ||
|
P2DSI-4155D2
|
-40~85℃ | ||
|
P4DSC-4155D2
|
-5~70℃ | 40Km | |
|
P4DSE-4155D2
|
-5~85℃ | ||
|
P4DSI-4155D2
|
-40~85℃ | ||
|
P6DSC-4155D2
|
-5~70℃ | 60Km | |
|
P6DSE-4155D2
|
-5~85℃ | ||
|
P6DSI-4155D2
|
-40~85℃ |
